Telecom & Grid Modernization

Kymberly Traylor, Director of Network & Telecommunications Services, JEA

Kymberly Traylor, Director of Network & Telecommunications Services, JEA

Traditionally, utilities have purchased, deployed, and attempted to integrate vendor “point [” solutions within the telecommunications domain. Most of these networks do not offer true interoperability. The convergence of expanding data (high bandwidth, low latency) and legacy transport systems demanded JEA develop a migration strategy. As the Director of Network & Telecommunications for JEA, I found myself in this dilemma: How do we support our lines of business in the leap from legacy technologies to Grid Modernization? The time for action is now; it is no longer a choice - it’s a necessity.

JEA had redesigned its data model for the aforementioned grid modernization efforts and we needed to undertake a similar initiative in regard to our networks. This would enable transport of exploding low latency data grid use cases that are common in our environment. JEA embarked on this effort over the past year to quantify and qualify its utility operations use cases based on the National Institute of Standards and Technology (NIST) Framework and Roadmap of Smart Grid Interoperability Standards, Release 4.0. We identified and characterized more than 100 utility operational Electric, and Water use cases for current and future state. Some of these core use cases included: Pole-Top Reclosers, Distribution Line Sensors, Faulted Circuit Indicators, Smart Regulators, Dynamic Water Consumption Monitoring, Capacitor Banks, Distributed Generation Devices, Multiple-EV Charging Stations, and Smart Inverters. Our plan to use further leverage IIoT capabilities to increase our service reliability and provide our employees with real-time asset status information that offers multiple options depending on the type, location, and bandwidth needs of the installed sensors.

EA had redesigned its data model for the aforementioned grid modernization efforts and we needed to undertake a similar initiative in regard to our networks. This would enable transport of exploding low latency data grid use cases that are common in our environment. JEA embarked on this effort over the past year to quantify and qualify its utility operations use cases based on the National Institute of Standards and Technology (NIST) Framework and Roadmap of Smart Grid Interoperability Standards, Release 4.0. We identified and characterized more than 100 utility operational Electric, and Water use cases for current and future state. Some of these core use cases included: Pole-Top Reclosers, Distribution Line Sensors, Faulted Circuit Indicators, Smart Regulators, Dynamic Water Consumption Monitoring, Capacitor Banks, Distributed Generation Devices, Multiple-EV Charging Stations, and Smart Inverters. Our plan to use further leverage IIoT capabilities to increase our service reliability and provide our employees with real-time asset status information that offers multiple options depending on the type, location, and bandwidth needs of the installed sensors.

Through a series of technology and business use case workshops, we reviewed the following technology options focusing on interoperable, secure, resilient, scalable, and flexible solutions that would allow us to adapt to future modern technology. (see Figure 1) –

During the development of our strategy, it became evident that a hybrid approach made the most sense, as there is no single solution that will meet all of JEA’s grid modernization needs. This model allows us to take an enterprise approach and leverage “best-of-breed” technology. In addition, we will be able to meet our customers where their needs are, i.e. high bandwidth, low latency, edge compute, automation, video, analytics etc. Our goal is to create a vendor-agnostic architecture to meet our organizational requirements

The development of the telecommunications strategy was based upon common industry principles that are critical to telecommunications. (See Figure 2) –

During the next nine to 12 months, we plan to run a pair of pilots leveraging core use cases to determine the best combination of wireless and wireline solutions for JEA. Based upon the outcome of these pilots we will complete our enterprise integrated grid planning and architecture design in conjunction with our business partners.

As JEA looks to modernize the grid, we need to keep in mind that we are not solving yesterday’s problems, but those of tomorrow.
